Heat Integration Using Aspen Energy Analyser
Pinch Technology is now well established for the design of energy systems. This workshop provides an introduction to the principles of pinch technology and the systematic procedures that have been developed to allow the targets to be achieved in practice. Methods for new heat exchanger network design will be developed. The ability to predict achievable energy targets for energy consumption which have a sound scientific basis is fundamental to the approach. Such targets can be used to scope and screen many design options effectively without having to carry out repeated designs. This workshop focuses on the design of heat exchanger networks using the Aspen Energy Analyser.
Workshop Highlights
- Introduction to Pinch Technology, its importance and application
- Introduction to Aspen Energy Analyser
- Generating Composite Curves and Grand Composite Curve (GCC) using Aspen Energy Analyser
- Energy Targets by Aspen Energy Analyser
- Identification of the heat recovery pinch
- Design Heat Exchanger Network using Aspen Energy Analyser(AEA)
Date: Saturday, September 28, 2024
Time: 9:00 AM - 6:00 PM
Last day of Registration: September 20, 2024
Fees
| Participants | Registration Fees |
|---|---|
| BTech Chemical Engineering Students | INR 500 + GST |
| MTech Chemical Engineering Students | INR 1000 + GST |
| Industry Employees | INR 5000 + GST |
Course Instructors
DHARAMSHI RABARI
Assistant Professor
School of Engineering and Applied Science
SRIDHAR DALAI
Assistant Professor
School of Engineering and Applied Science
Schedule
| Time | Day 1 |
|---|---|
| 9:30 AM - 11:00 AM | Session 1 |
| 11:00 AM - 11:30 AM | Tea Break |
| 11:30 AM - 1:00 PM | Session 2 |
| 1:00 PM - 2:00 PM | Lunch |
| 2:00 PM - 3:30 PM | Session 3 |
| 3:30 PM - 3:45 PM | Tea Break |
| 3:45 PM - 5:30 PM | Session 4 |
Session 1
- Introduction to Pinch Technology, its importance and application
- Key steps of pinch technology
- Composite curve- Hot Composite Curve (HCC) and Clod Composite Curve (CCC),
- Energy targeting by Composite Curve using Excel
- Hands on
- Energy target calculation based on with and without integration
- Manually construct composite curves and obtain energy targets
Session 2
- Problem Table Algorithm (PTA) Method, Grand Composite Curve (GCC)
- Energy targeting by PTA using Excel
- Introduction to Aspen Energy analyser (AEA)
- Hands on
- Energy target calculation by Composite curve and the PTA method using Excel
- Creating HI case and Entering the process and utility data in Aspen Energy Analyser (AEA)
- Identify the Energy target using the Aspen Energy Analyser (AEA)
Session 3
- Pinch Design Methods (PDM),
- Heat Exchanger Network (HEN) Design
- Hands on
- Design HEN for single pinch problem-Manually
- Case study
Session 4
- Introduce the Grid diagram representation of the Heat exchanger Network in the Aspen Energy Analyser (AEA)
- Design the HEN/ MER diagram using the Aspen Energy Analyser (AEA)
- Hands on
- Creating HI case and Entering the data for Energy target calculation
- Identify Energy Target and Heat Exchanger Design using the Aspen Energy analyser (AEA)
